INSWING ALuminum casement/PIVOT window
Design OVERVIEW
Narrow profile with a thermal break
Unique pressure-compensating gasket system
“European Style” multi-point locking system
Sash swing into the room for ventilation and cleaning
Frame depth 3.875"
1" to 1.25" insulating glass with a variety of options (Low-E, Laminated, Tempered, Obscure, etc.)
Bronze or Clear Anodized spacer between the glass
Available with surface mounted and “between-the-glass” style muntin grids
Standard and custom panning to match landmark conditions
Fiberglass mesh screens
Performance (AAMA/WDMA/CSA 101/I.S.2/A440-08)
Performance class CW-PG60 (Design Pressure 60.15 psf)
Air Infiltration 0.03 cfm/sq. ft
More water resistant: water penetration resistance pressure 12.11 psf
Better acoustical performance: STC 38, OITC 30 (glass combination: 1/4" Lami, 11/16" argon, 5/16" Lami)
Thermally efficient: U-Factor 0.40
Hardware
Handles and flat operators are available in standard and premium finishes:
Polished Chrome (standard)
Gunmetal, Nickel Pearl, Black Chrome (premium)
Frame Finish OPTIONS
Casement windows are available in single or two-color options:
Interior: Bronze, White and Off-White
Exterior: Bronze, Black and Aluminum Grey
Custom-painted finishes are also available
